Description
Air Blower
- All units are manufactured in die-cast aluminum alloy
- Standard motors are two pole, totally enclosed air cooled, and continuous duty rated
- IP54 protection rated
- Insulation class F
- Max temperature 40°C
- Special voltages available on request
| Model | Power | Voltage (V) | Tolerance (m2/min) | Pressure (mmH2O) | Noise (dB) | |
| (Hp) | (KW) | |||||
| PAB-1.0 | 1 | 0.75 | 220V | 2 | 1850 | <60 |
| PAB-1.5 | 1.5 | 1.2 | 220V | 2.4 | 1950 | <65 |
| PAB-2.0 | 2 | 1.5 | 220V | 3.2 | 1950 | <70 |
| PAB-3.0 | 3 | 2.2 | 220/380V | 5 | 2200 | <75 |
| Model | A | B | C | D | E | F | F1 | G | H | J | M | N | O | Q |
| (mm ) | (mm ) | (mm ) | (mm ) | (mm ) | (mm ) | (mm ) | (mm ) | (mm ) | (mm ) | (mm ) | (mm ) | (mm ) | (Inch ) | |
| PAB-1.0 | 395 | 415 | 315 | 125 | 290 | 320 | 83 | 15 | 74 | 217 | 110 | 140 | 332 | 2” |
| PAB-1.5 | 395 | 415 | 315 | 125 | 290 | 320 | 83 | 15 | 74 | 217 | 110 | 140 | 332 | 2” |
| PAB-2.0 | 395 | 415 | 315 | 125 | 290 | 320 | 83 | 15 | 74 | 217 | 110 | 140 | 332 | 2” |
| PAB-3.0 | 395 | 415 | 315 | 125 | 290 | 320 | 83 | 15 | 74 | 217 | 110 | 140 | 332 | 2” |
